Nissan Skyline R32/33

Nissan Skyline R32, Nissan Skyline R33 Variations: GT-R, GTS-t
Engine Codes: RB20DET, RB25DET, RB26DETT
Transmission: Manual only (Automatic not supported)

Nissan Skyline R32/33

  • Features:
    • Direct plug and play replacement of the OEM ECU, no re-wiring necessary.
    • Uses the cars factory sensors
    • Supports R32 GT-R twin MAF sensors
    • Supports Sequential Injection (peak and hold) and Direct fire ignition
    • Windows 2000, XP, Vista, Windows 7 compatible software
    • Real time programming, instant hesitation free adjustment while engine is running
    • Fully user definable 32 x 32 mapping
    • Tuning via Volumetric Efficiency (VE), Injection time or Lambda Correction (MAF)
    • OBD II Code Storing & Malfunction Indicator Light (MIL) Control (Access through laptop
    only )
    • Selectable onboard internal MAP sensor rated to 150kPa (up to 1.5 Bar or 22psi boost)
    • Wideband “auto tuning” using user definable target AFR table
    • Flex Fuel Support
    • USB and CAN Communication Port

    Factory Outputs:
    • 6 x Fuel Injector outputs
    • 6 x Ignition outputs
    • Tacho, Boost Control, AC Clutch Relay, Idle Control
    • Thermo Fan, Check Engine Light, Fuel Pump (Variable Speed)
    • N-VCT ( Nissan Variable CAM Timing Control)

    Factory Inputs:
    • MAF sensors, Throttle Position Sensor, Oxygen sensors,
    • Coolant Temperature sensor, Vehicle Speed Sensor,
    • Air Temperature sensor.

    Expansion I/O*:
    • 4 x Analogue voltage inputs (with switchable pull up)
    • 1 x Digital pulsed input
    • 2 x Digital pulsed outputs
    • 2 x Digital switched outputs

    *Optional auxiliary harness can be purchased Haltech Part # HT-040003

    • Closed Loop O2 Control
    • Decel Cut Over Boost Rev Limiter
    • Closed & Open Loop Boost Control
    • Gear Setup
    • ACF On Base Tables
    • Transient Throttle Enhance

    Correction Tables: Fuel Ignition Boost:
    • Cranking
    • Air Temp Target Correction
    • Coolant Temperature Correction
    • Map Correction
    • Zero Throttle Gear Correction
    • Cylinder Trim
    • TPS Correction
    • Generic Correction 1
    • Generic Correction 2
    • Gear Correction
    • Post Start
    • Air Temp Duty Correction
    • Post Start
